OS：MagicUI Router
CPU：IPQ5018, dual-core 1GHz processor
RAM ：memory: 256M RAM (Byte)
ROM： flash memory: 128M FLASH (Byte)
Transmission standard ：802.11ax/ac/n/a 2*2&802.11ax/n/b/g 2*2
Wireless rate ：dual-band concurrent, 3000Mbps (2.4GHz: 574Mbps, 5GHz: 2402Mbps)
Wireless frequency band： 2.4GHz & 5GHz, support dual frequency optimization
Security features ：Wi-Fi anti-brute force cracking, automatically shield crackers; support a new generation of wireless encryption protocol WPA3; support firewall, DMZ, DoS attack protection, etc.
Antenna gain： 2.4G 5dbi 5G 6dbi
Antenna type ：Four external high-performance antennas
Network port transmission protocol ：802.3, 802.3u, 802.3ab
Mobile App supports： APP local/remote management
WiFi mode supports three modes: through-wall, standard, sleep
QoS features support device speed limit: limit device bandwidth by MAC address
Features support game/online class acceleration, 802.11v seamless roaming protocol, IPv6/IPv4, dual-band optimization, blind insertion of network ports, automatic channel optimization in time, PPPoE/DHCP/static IP/MAC address cloning/Bridge AP Internet access, Wi-Fi relay, Wi-Fi timer switch, guest Wi-Fi, networked device management, MAC address filtering, children's Internet protection, VPN transparent transmission, DMZ/virtual server and other functions
The network port provides four 10M/100M/1000M self-adaptive rate Ethernet interfaces, and supports WAN/LAN self-adaptation (blind insertion of network ports)
Power Specifications： 12V DC, 1 A
The power consumption of the whole machine is less than 12 W
Hi button supports MagicLink router one-key networking, compatible with WPS
Reset button ：Independent Reset reset button
